English
www.stryker.com 2131-009-005 REV A 1-69
Return To Table of Contents
Right Fit Oxygen Bottle Holder - FA64203
The Optional Right Fit Oxygen Bottle Holder is designed to support the oxygen bottle on the headboard.
INSTALLATION
Required Tools: None
1. Install bottle holder (A) on headboard (B).
2. Screw the holder handle (C) until the holder is installed properly on the headboard.
3. Route the number 3 straps (D and E) through the holes in the headboard and attach them to their fasteners.
4. Insert the oxygen bottle in the holder.
5. Install the cover (F) on the holder and tie the number 1 straps (G) together.
Note: The cover is reversible. It can be placed so that the opening is on the right or on the left of the bed to
ease the use.
A
B
C
D
E
F
Insert the oxygen bottle here.
