Subaru Outback 2011 - Ventilators

Black plate (198,1)
一般Model "A2470GE-B" EDITED: 2010/ 9/ 24
4-4 Climate control
& Ventilators
! Center ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the center grille
open/close wheel to the “
” position.
To close it, turn the wheel to the “
”
position.
! Side ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the side grille
open/close w heel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
! Rear ventilators (if equipped)
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the rear grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
