1
1-68
Maintenance
and
service
remove
it.
4.
Install
a
new
bulb.
5.
Reinstall
the
lens.
&
V
anity
mirror
light
1.
Remove
the
lens
by
prying
the
edge
of
the
lens
with
a
flat-head
screwdriver
.
2.
Pull
the
bulb
out
of
the
socket.
3.
Install
a
new
bulb.
4.
Reinstall
the
lens.
&
Door
step
light
1.
Remove
the
lens
by
prying
the
edge
of
the
lens
with
a
flat-head
screwdriver
.
2.
Pull
the
bulb
out
of
the
socket.
3.
Install
a
new
bulb.
442
444
