Clutch pedal (MT models)
Check the clutch pedal free play and
reserve distance according to the main-
tenance schedule.
& Checking the clutch function
Check the clutch engagement and disen-
gagement.
1. With the engine idling, check that there
are no abnormal noises when the clutch
pedal is depressed, and that shifting into
1st or reverse feels smooth.
2. Start the vehicle by releasing the pedal
slowly to check that the en gine and
transmission smoothly couple without
any sign of slippage.
& Checking the clutch pedal
free play
1) 5 – 11 mm (0.19 – 0.43 in)
Lightly depress the clutch pedal down with
your finger until you feel resistance, and
check the free play.
If the fre e play is not within proper
specification, we recommend that you
contact your SUBARU dealer.
Replacement of brake pad
and lining
The right front disc brake and the right rear
disc brake have audible wear indicators
on the brake pads. If the brake pads wear
close to the ir service limit, the wear
indicator makes a very audible scraping
noise when the brake pedal is applied.
If you hear this scraping noise each time
you apply the brake pedal, we recommend
that you have the brake pads serviced by
your SUBARU dealer as soon as possible.
CAUTION
If you continue to drive despite the
scraping no ise f rom the audible
brake pad wea r indicat or, it will
Maintenance and service 11-41
– CONTINUED –
