11-62 Maintenance and service
& Rear combination lights
! Sedan
NOTE
It may be difficult to replace the bulbs.
We recommend that you have the bulbs
replaced by your SUBARU dealer if
necessary.
1. Turn the knob s of the cover 90
degrees counterclockwise to remove the
cover.
1) Brake/tail light
2) Rear turn signal light
3) Back-up light
2. Remove the bulb holder from the rear
combination light assembly by turning it
counterclockwise. Use pliers if necessary.
3. Pull the bulb out of the bulb holder and
replace it with a new one.
4. Set the bulb holder in to the rear
combination light assembly and turn it
clockwise until it locks.
5. Securely lock the cover against the
trunk trim.
! Station wagon
1. Undo the clips. For the method to undo
the clips, refer to “Type C clips” F11-9.
2. Remove the cover.
3. Remove the upper and lower screws.
To Next Page
