一般Model "A2470GE-B" EDITED: 2010/ 9/ 24
7. Instal l the air cle aner element b y
covering the clamp with a hand, to avoid
scratching the air cleaner element.
8. Install the removed parts in the reverse
order of removal.
Spark plugs (petrol engine
models)
It may be difficult to replace the spark
plugs. It is recommended that you have
the spark plugs replaced by your
SUBARU dealer.
The spark plugs should be replaced
according to the maintenance schedule.
Refer to “Maintenance schedule” F11-3.
& Recommended spark plugs
Refer to “Electrical system” F12-11.
Drive belts
& Models with a hydraulic
power steering system
! Except 3.6 L models
1) Power steering pump pulley
2) Front side belt
3) Alternator pulley
4) Air conditioner compressor pulley
5) Rear side belt
6) Crank pulley
A) 98 N (10 kgf, 22 lbf)
CAUTION
The drive belt, which runs in con-
junction with the following compo-
nents, must be used within the
Maintenance and service 11-29
– CONTINUED –
