Black plate (208,1)
Model "A2470GE-B" EDITED: 2010/ 9/ 24
4-14 Climate control
CAUTION
The arrow mark on the filter must
point UP.
8. Insert the shelf as illustrated.
9. Connect the connector.
10. Install the shelf.
11. Reinstall the glove box, and connect
the damper shaft.
12. Close the glove box.
13. LABEL installation
(1) Fill o ut the in formation o n the
service label (small).
