4. Unscrew the red cap of the sealant
bottle.
CAUTION
Leave the bottle seal intact. Screw-
ing the bottle onto the bottle holder
will pierce the seal of the bottle.
Avoid skin contact with the sealant,
which contains natural rubber latex.
1) Bottle holder
5. Screw the bottle clockwise firmly
against the slight resistance of the
notches onto the sealing gasket of the
bottle holder until it is screwed tight.
6. Remove the valve cap from the da-
maged tire.
1) Protective cap
2) Hose
3) Pressure relief valve
7. Pull the protective cap off the end of
the hose and screw the hose firmly onto
the valve of the damaged tire. Ensure that
the pressure relief valve is tight.
1) Compressor switch
8. Make sure that the compressor switch
is switched to “0”.
9. Insert the power plug into the acces-
sory power outlet located below the
climate control. Refer to “Accessory power
In case of emergency 9-15
