Subaru Outback 2011 - Page 461

Black plate (477,1)
一般Model "A2470GE-B" EDITED: 2010/ 9/ 24
Fuse
panel
Fuse
rating
Circuit
14 15A
. Engine control unit
15 15A
. Ignition coil
16 15A
. Engine control unit
17 15A
. Engine control unit
18 10A
. Automatic transmission
control unit
19 10A
. Illumination
20 10A
. Rear combination light
21 15A
. Turn and hazard warn-
ing flasher (body control
unit)
22 20A
. Door lock (body control
unit)
23 15A
. Rear wiper
. Rear washer
24 10A
. Front washer
25 30A
. Front wiper
26 25A
. Rear window defogger
. Mirror heater
. Front wiper deicer
27 10A
. Secondary air combina-
tion valve (2.0 L mod-
els)
28 15A
. Blower fan
29 15A
. Blower fan
Fuse
panel
Fuse
rating
Circuit
30 25A
. Audio unit
31 25A
. Sub fan
32 25A
. Main fan
33 30A
. ABS/Vehicle dynamics
control unit
34 7.5A
. Glow plug (diesel en-
gine models)
35 10A
. Fog light (right side)
36 10A
. Fog light (left side)
37 10A
. Back-up (body control
unit)
