SummaCut User’s Manual
General Information 1-20
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING
AREA. THERE ARE HAZARDOUS MOVING PARTS.
6. The cutter is now ready for the actual load procedure; it starts once the
pinchrollers are closed. Lower the pinch roller lever to press the media firmly
against the drive sleeves. After one second the tool carriage automatically
moves from the right to the left to sense the usable media width.
NOTE
It is not necessary to unroll the media manually from the roll. The cutter will
unroll the media automatically during the load sequence.
7. The positioning and routing of sheet material is identical to that of roll media.
Here the alignment strip has to be used to be sure that the media lays straight.
SAFE OPERATION
Do not place any objects in front of, or behind, the cutter that could
interfere with cutter operation. Make sure the media is free to move
back and forth. Keep hands, hair, clothing and jewellery away from
moving parts.
If the cutter isn’t switched on, switch the power on and the following message will
appear on the LCD screen:
.. . .... . .
The cutter will automatically start executing a minimal loading procedure when there is
media in the cutter and the pinch rollers are down consisting of:
- a media width measurement
- a 45° test
- media is unwound over a length equal to the width measured
between the pinch rollers
When the next display appears, the cutter is ready to receive a file:
For a manual loading procedure refer to paragraph 2.2.10
When sending a cut file, the cutter will automatically pull the required media from the
roll. The pulling is done in steps such that for each step the length pulled off the roll is
identical to the width measured between the pinch rollers.
