UltraSPARC User’s Manual
ASI_UDBH_ERROR_REG_READ External UDB Error Register, read high 7F
16
ASI_UDBH_ERROR_REG_WRITE External UDB Error Register, write high 77
16
ASI_UDBL_CONTROL_REG_READ External UDB Control Register, read low 7F
16
ASI_UDBL_CONTROL_REG_WRITE External UDB Control Register, write low 77
16
ASI_UDBL_ERROR_R External UDB Error Register, read low 7F
16
ASI_UDBL_ERROR_REG_READ External UDB Error Register, read low 7F
16
ASI_UDBL_ERROR_REG_WRITE External UDB Error Register, write low 77
16
ASI_UDB_CONTROL_W External UDB Control Register, write high 77
16
ASI_UDB_CONTROL_W External UDB Control Register, write low 77
16
ASI_UDB_ERROR_W External UDB Error Register, write high 77
16
ASI_UDB_ERROR_W External UDB Error Register, write low 77
16
ASI_UDB_INTR_R Incoming interrupt vector data register 0 7F
16
ASI_UDB_INTR_R Incoming interrupt vector data register 1 7F
16
ASI_UDB_INTR_R Incoming interrupt vector data register 2 7F
16
ASI_UDB_INTR_W Interrupt vector dispatch 77
16
ASI_UDB_INTR_W Outgoing interrupt vector data register 0 77
16
ASI_UDB_INTR_W Outgoing interrupt vector data register 1 77
16
ASI_UDB_INTR_W Outgoing interrupt vector data register 2 77
16
ASI_UPA_CONFIG_REG UPA configuration register 4A
16
Table F-1 ASI Names (Alphabetical) (Continued)
ASI Name or Macro Syntax Description Value
