Sun Microelectronics
68
UltraSPARC User’s Manual
6.9.11 I-/D-Demap Page (Type=0)
Demap Page removes the TTE (from the specified TLB) matching the specified
virtual page number and context register. The match condition with regard to the
global bit is the same as a normal TLB access; that is, if the global bit is set, the
contexts need not match.
Virtual page offset bits <15:13>, <18:13>, and <21:13>, for 64Kb, 512Mb, and 4M
bpage TLB entries, respectively, are stored in the TLB, but do not participate in
the match for that entry. This is the same condition as for a translation match.
Note: Each Demap Page operation removes only one TLB entry. A demap of a
64 Kb, 512 Kb, or 4 Mb page does not demap any smaller page within the
specified virtual address range.
6.9.12 I-/D-Demap Context (Type=1)
Demap Context removes all TTEs having the specified context from the specified
TLB. If the TTE Global bit is set, the TTE is not removed.
6.10 MMU Bypass Mode
In a bypass access, the D-MMU sets the physical address equal to the truncated
virtual address; that is, PA<40:0>=VA<40:0>. The physical page attribute bits are
set as shown in Table 6-16.
Bypass applies to the I-MMU only when it is disabled. See Section 6.7, “MMU Be-
havior During Reset, MMU Disable, and RED_state,” on page 54 for details on
the use of bypass when either MMU is disabled.
Compatibility Note:
In
UltraSPARC the virtual address is longer than the physical address; thus,
there is no need to use multiple ASIs to fill in the high-order physical address bits,
as is done in SPARC-V8 machines.
Table 6-16 Physical Page Attribute Bits for MMU Bypass Mode
ASI
Physical Page Attribute Bits
CP IE CV E P W NFO Size
ASI_PHYS_USE_EC
ASI_PHYS_USE_EC_LITTLE
10000108Kb
ASI_PHYS_BYPASS_EC_WITH_EBIT
ASI_PHYS_BYPASS_EC_WITH_EBIT_LITTLE
00010108Kb
