UltraSPARC User’s Manual
17.5 Integer Execution Unit (IEU) Instructions
IEU instructions can be dispatched only if they are in the first three instruction
slots. A maximum of two IEU instructions can be executed in one cycle. There are
two IEU pipelines: IEU
0
and IEU
1
. The two data paths are slightly different, and
some IEU instructions can be dispatched only to a particular pipeline. The fol-
lowing instructions can dispatched to either IEU pipeline: ADD, AND, ANDN, OR,
ORN, SUB, XOR, XNOR and SETHI. These instructions can be grouped together or
with older IEU
0
or IEU
1
specific instructions.
The IEU
0
data path has dedicated hardware for shift instructions: SLL{X}, SRL{X}.
SRA{X}. Two shift instructions cannot be grouped together. Shift instructions can
be grouped with older IEU
1
specific instructions, but they cannot be grouped
with older non-specific IEU instructions. For example:
The IEU
1
datapath has dedicated hardware for the condition-code-setting instruc-
tions: (TADDcc{TV}, TSUBcc{TV}, ADDcc, ANDcc, ANDNcc, ORcc, ORNcc, SUBcc,
XORcc, XNORcc), EDGE and ARRAY. CALL, JMPL, BPr, PST and FC-
MP{LE,NE,GT,EQ}{16,32}
also require the IEU
1
data path (besides counting as CTI,
store, or floating-point instructions respectively), since they must access the inte-
ger register file. Two instructions requiring the use of IEU
1
cannot be grouped to-
gether; for example, only one instruction that sets the condition codes can be
dispatched per cycle. An IEU
1
instruction can be grouped with older shift in-
structions and non-specific IEU instructions.
Note: For UltraSPARC-II, a valid control transfer instruction (CTI) that was
fetched from the end of a cache line is not dispatched until its delay slot also has
been fetched.
17.5.1 Multi-Cycle IEU Instructions
Some integer instructions execute for several cycles and sometimes prevent the
dispatch of subsequent instructions until they complete.
MULScc inserts one bubble after it is dispatched.
SDIV{cc} inserts 36 bubbles, UDIV{cc} inserts 37 bubbles, and {U,S}DIVX inserts 68
bubbles after they are dispatched.
ADD i1, i2, i6 GECN
1
N
2
N
3
W
SLL i6, 2, i8 GECN
1
N
2
N
3
W
