SunSynk INNAGATOR - Dimensions and Ratings; External Dimensions; Internal Dimensions (Nominal); Front Door Opening Dimensions

Innagator | Technical Pack16
Dimensions and Ratings
External Dimensions
Dimensions Meters Feets
Length 6,058 m
+0 mm
19'101/2"
+0
-6 mm -1/4"
Width 2,438 m
+0 mm
8'
+0
-5 mm -3/16"
Height 2,896 m
+0 mm
9'6"
+0
-5 mm -3/16"
a. No part of the container will protrude beyond the external dimensions mentioned above.
b. Maximumallowabledierencesbetweentwodiagonalsonanyoneofthefollowingsurfaceswillbeas
follows:
Internal Dimensions (Nominal)
Dimensions Meters Feets
Length 5,795 mm 19'01/8"
Width 2,235 mm 7'4"
Height 2,590 mm 8'561/64"
Dimensions Meters Feets
Roof, bottom and
side diagonals
13 mm 1/2"
Front and rear
diagonals
10 mm 3/8"
Front Door Opening Dimensions
Front Door Opening Dimensions
Internal Cubic Capacity (Nominal)
Dimensions Meters Feets
Width 2,338 m
+0 mm
7’81/16"
+0
-5 mm -3/16"
Height 2,580 m
+0 mm
7’445/64"
+0
-5 mm -3/16"
Dimensions Meters Feets
Width 1,818 m
+0 mm
5’119/16"
+0
-5 mm -3/16"
Height 2,580 m
+0 mm
7’445/64"
+0
-5 mm -3/16"
Meters Feets
30.2 cu.m 1,070 cu.ft
