SunSynk INNAGATOR - Installation of Rack

Innagator | Technical Pack152
Installation of Rack
1. Connect the upper cross beams (102) and lower cross beams (103) with the two rack sides (102) using
M6*12 external hexagonal cross combination screws (108) and a PHILIP2 # screwdriver.
