Program Charge & Discharge Times
To set ‘Charge’ and ‘Discharge’ times, click on the ‘System Mode’ icon after clicking on the gear icon.
What this page displays:
 A setting to prevent the inverter exporting power to the grid - ‘Zero Export’.
 The ability to limit power supply to only the household loads - ‘Solar Export’.
 Set the power limits to supply only the loads connected to the LOAD port - ‘Priority to Load Only’.
If nothing ticked: This Mode allows the hybrid inverter to sell back any excess power produced by the solar
panels to the grid. If the use time is active, the battery energy can also be sold into the grid. The PV energy
willbeusedtopowertheloadandchargethebattery,andthenexcessenergywillowtothegrid.Power
source priority for the load is as follows:
1. Solar Panels.
2. Grid.
3. Batteries (until programmable % discharge is reached).
Zero Export + Limit To Load Only: The hybrid inverter will only provide power to the backup load connect-
ed. The hybrid inverter will neither provide power to the home load nor sell power to the grid. The built-in CT
willdetectpowerowingbacktothegridandwillreducethepoweroftheinverteronlytosupplythelocal
load and charge the battery.
GridBackup Load On-Grid Home Load
Battery
Solar
