SunSynk INNAGATOR - Hvac System; ATOM B Series - Heat Pump

Innagator | Technical Pack52
HVAC SYSTEM
ATOM B Series - Heat Pump
Model MDV-V56WDHN1(AtB)
Power Supply 220-240V/1Ph/ 50(60)Hz
Cooling
[1]
Capacity
52 kBtu/h
15.5 kW
Input 4.87 kW
EER 3.18 kW/kW
Heating
[2]
Capacity
61 kBtu/h
18 kW
Input 4.82 kW
COP 3.73 kW/kW
Connectable Indoor Unit
Total Capacity 45~130% of outdoor unit capacity
Quantity 1~9
Compressor
Type DC inverter
Quantity 1
Oil Type RB74AF
Fan
Motor Type DC motor
Quantity 1
Output 170 W
Outdoor Air Flow 5000 m
3
/h
Sound Pressure Level
[3]
56 dB(A)
Net Dimensions (W×H×D) 950×840×440 mm
Packed Dimensions (W×H×D) 1025×950×510 mm
Net Weight 77.5 kg
Gross Weight 84.5 kg
Refrigerant
Type R410A
Factory Charge 3600 g
Throttle Type Electronic expansion valve
Pipe Connections
Liquid Pipe Ф9.53mm
Gas Pipe Ф19.1mm
Ambient Temp. Operation
Range
Cooling -15~55 ºC
Heating -15~27 ºC
[1]
Indoortemperature27°CDB,19°CWB;outdoortemperature35°CDB;equivalentrefrigerantpiping
length7.5mwithzeroleveldierence;connecttoCassettetypeindoorunit.
[2]
Indoortemperature20°CDB;outdoortemperature7°CDB,6°CWB;equivalentrefrigerantpipinglength
7.5mwithzeroleveldierence;connecttoCassettetypeindoorunit.
[3]
Soundpressurelevelismeasuredataposition1minfrontoftheunitand1mabovetheoorina
semi-anechoic chamber.
