Construction
The container will be meticulously constructed using robust steel frames, featuring fully vertical-corrugated
steel sides and a front wall. At the rear end, it will have horizontal-corrugated steel double doors for con-
venientaccess.Thecontainerwillalsoincludeanopenablehardroofframeandcornerttingsforsecure
handling and transportation.
To ensure optimal strength and durability, all exterior welds, including the base frames, will be meticulous-
ly performed using continuous welding techniques with CO2 gas. For necessary interior welds, a stitching
method will be employed with a minimum stitch length of 15 mm, ensuring structural integrity and minimiz-
ing potential weak points.
The gaps between adjacent components to be welded will be strictly controlled, not exceeding 3 mm or the
thickness of the parts being welded. This meticulous approach guarantees a tight and secure construction.
To enhance the container's water tightness, chloroprene sealant will be carefully applied at the periphery
oftheoorsurfaceandinsideunweldedseams.Additionally,butylsealantwillbeusedtocaulktheinvisible
seamoftheoorjointareaandbetweenthedoorgasketandframe,providinganeectivebarrieragainst
moisture ingress.
The internal bend radii of pressed sections of steel will be designed to be not less than 1.5 times the thick-
ness of the materials being pressed. This ensures structural integrity, prevents stress concentrations, and
maintains the overall strength of the container.
Byadheringtothesestringentconstructionspecications,thecontainerwillmeetthehigheststandardsof
durability, water tightness, and structural integrity, ensuring reliable performance in various transportation
and storage scenarios.
General
The lower faces of all transverse members will be positioned 12.5 mm +5/-1.5 mm above the plane formed
bythelowerfacesofthebottomcornerttings.Thisprecisepositioningensuresproperalignmentandsta-
bility.
Theoutsidefacesofthecornerttingswillprotrudefromtheoutsidefacesofthecornerpostsbyapproxi-
mately 3-4 mm, providing a secure and visible connection point.
Theoutsidefacesofthecornerttingswillextendbeyondtheoutsidefacesofthesidesandfrontwallby
approximately 7-8 mm, allowing for proper alignment and secure stacking of containers.
At maximum payload, no part of the container will extend below the plane formed by the lower faces of the
bottomcornerttings,evenduringmaximumdeection.Thisensuresthatthecontainerremainswithinsafe
limits and prevents any protrusions that may interfere with handling or transportation.
Under a load of 1.8 times the maximum gross weight, no part of the container will protrude more than 6.0
mmbelowtheplaneformedbythelowerfacesofthebottomcornerttings.Thisspecicationensuresthat
the container maintains its structural integrity and dimensional stability even under increased stress.
Thesepreciseprotrusionspecicationsguaranteethesafeandecienthandling,stacking,andtransporta-
tion of the container, while ensuring compliance with industry standards.
