SunSynk INNAGATOR - Gas Fire Extinguishing System Design

Innagator | Technical Pack33
1. Technical Standards and Specications
 EN54-23:2010Firedetectionandalarmsystems-Part23:Firealarmequipment-ashalarm;
 EN ISO 13943:2000 Fire safety vocabulary;
 EN 54-5-2017 Fire detection and alarm systems - Part 5: Point type temperature detectors;
 EN 54-7-2000 Fire detection and alarm systems - Part 7: Smoke detectors. Point detectors with scat-
tered, transmitted, or ionized light are used;
 EN 54-11-2001 Fire detection and alarm systems - Part 11: Manual alarm buttons;
Gas Fire Extinguishing System Design
2. Categories of Gas Fire Extinguishing Systems
Useperuorohexanonere-extinguishingsystem.Afterllingthereextinguishingagent,pressurizenitro-
gen to 2. 5MPa.
Peruorohexanonereextinguishingsystemmainlycomprisesanextinguishingagentbottleset,pressure
gauge, lucky starter, release hose, pressure signal feedback device, pipe network, nozzle, etc., with CE, VdS
internationalcertication.
3. Setting of Gas Protection Area
See system calculation table for details.
4. Setting of Fire Extinguishing System
Setupperuorohexanonereextinguishingsystem.
5. Design Parameters
 The environment temperature:20°C
 Extinguishing concentration/inerting concentration: determined according to combustibles' maxi-
mum extinguishing design concentration or inerting design concentration.
 Discharge time: The design discharge time should not exceed 10s.
 Fire immersion time:Wood,appropriateuseof20min.Otherpaper,fabric,andothersolidsurfacere,
thecombustiblereshouldbeusedfor10minutes.
7. Fire Extinguishing System Starting Mode
 Automatic Activation:Thesysteminitiatesautomaticallyupondetectingareorsmoke,ensuringswift
response and minimizing potential damage. This mode guarantees immediate action without any human
intervention.
 Manual Activation Button: In addition to automatic activation, the system features a clearly labeled and
easilyaccessiblemanualactivationbutton.Thisprovidesanoptionforindividualstoinitiatethereextin-
guishing process if needed, such as in case of a false alarm or when immediate action is required before
the automatic mode activates.
 Mechanical emergency manual is included.
6. Amount of Extinguishing Agent
See system calculation table for details.
