Innagator | Technical Pack93
Earth Connection (MANDATORY)
Ground cable shall be connected to ground plate on grid side this prevents electric shock if the original pro-
tective conductor fails.
Model Wire size Cable (mm
2
) Torque value (max)
50kW 0 AWG 53.5 20.3Nm
The conductor should be made of the same metal as the phase conductors.
STRICTLY, PRIVATE AND CONFIDENTIAL
