1. Then, insert AC output wires according to the polarities indicated on the terminal block and tighten the
terminal. Make sure to connect corresponding N wires and PE wires to related terminals as well.
2. Ensure the wires are securely connected.
3. Appliances such as air conditioners require at least 2-3 minutes to restart because it requires enough
time to balance refrigerant gas inside the circuit. If a power shortage occurs and recovers in a short time,
it will cause damage to your connected appliances. To prevent this kind of damage, please check with the
air conditioner manufacturer if it is equipped with a time-delay function before installation. Otherwise,
thisinverterwilltriggeranoverloadfaultandcutooutputtoprotectyourappliance,butsometimesit
still causes internal damage to the air conditioner
WARNING
Ensure the AC power source is disconnected before attempting to wire it to the unit.
PV Connection
Before connecting to PV panels, install a separate DC circuit breaker between the inverter and PV modules.
In addition, we request users install PV junction boxes with surge protection to protect the system from a
lightning strike. External AC SPD is compulsory on all Sunsynk inverters.
To avoid any malfunction, do not connect any PV modules with possible current leakage to the inverter. For
example, grounded PV modules will cause current leakage to the inverter.
In order to reduce risk of injury, please use the recommended cable sizes as shown below:
PV Module Selection
When selecting proper PV modules, please be sure to consider below parameters:
1. Open circuit voltage (Voc) of PV modules can not exceed the max. PV array open circuit voltage of the
inverter.
2. Open circuit voltage (Voc) should be higher than min. start voltage.
3. ThePVmodulesconnectedtothisinvertershallbeClassAratingcertiedaccordingtolEC61730.
WARNING
To avoid malfunction, do not connect any PV modules with possible leakage current to the inverter.
For example, grounded PV modules will cause leakage current to the inverter. When using PV mod-
ules, please ensure the PV+ & PV- of the solar panel are not connected to the system ground bar.
It is requested to use a PV junction box with surge protection. Otherwise, it will cause damage to the
inverter when lightning occurs on PV modules.
Inverter Model 50kW
PV Input Voltage 600V (180V~1000V)
PV Array MPPT Voltage Range 150-850V
No. Of MPP Trackers 4
No. Of Strings per MPP Tracker 2+2+2+2
