SunSynk INNAGATOR - Ratings; Materials; Specifications

Innagator | Technical Pack17
Ratings
Measure Kilograms Pounds
Max. Gross Weight (R) 30,480 kg 67,200 lbs
Tare Weight (design) (T) 4,000 kg 8,820 lbs
Max. Payload (P) 26,480 kg 58,380 lbs
Materials
The following materials will be used in the construction of containers.
Specications
Material Application
Anti-corrosive steel. SPA-H or equivalent
Y.P.
[1]
: 343 N/mm
2
T.S.
[2]
: 481 N/mm
2
All steel except screws, rivets, bolts/nuts, door
hardware, and others are shown on drawings and
specications.
Rolled high tensile steel. SM490A (SM50A)
Y.P. : 324 N/mm
2
T.S. : 490 N/mm
2
Rear corner posts (inner);
Door swing header;
Top side rail
Rolled high tensile steel. SM490A (SM50A)
Y.P. : 324 N/mm
2
T.S. : 490 N/mm
2
Rear corner posts (inner)
Door swing header
Top side rail
Structural steel round pipe. STK400 (STK41)
Y.P. : 235 N/mm
2
T.S. : 402 N/mm
2
Door locking bars
Roof bows
Casted weldable steel. SCW480 (SCW49)
Y.P. : 275 N/mm
2
T.S. : 480 N/mm
2
Cornerttings
S20C
Y.P. : 245 N/mm
2
T.S. : 402 N/mm
2
Locking gear cams and keepers
S25C
Y.P. : 265 N/mm
2
T.S. : 441 N/mm
2
Door hinges
Swing head hinges and lug
Stainless steel
Door hinge pins
Door header pins
Gasket retainers
EPDM Door gasket
t4.0 CHECK PLATE Floor board
[1]
Y.P. – Min. Yield point
[2]
T.S. – Min. Tensile strength
