Innagator | Technical Pack25
 This design is a full submersion system. According to the requirements of the current code and the
actual situation of this project, a set of unit-independent systems is set up for the protection area in this
project.
 ThereresistancelimitoftheenclosurestructureanddoorsandWindowsoftheprotectedareashould
notbelessthan0.5h,andthereresistancelimitoftheceilingshouldnotbelessthan0.25h.The
allowable pressure of the envelope structure and doors and Windows should not be less than 1200Pa.
Thesashintheprotectionareaisnotaxedsashandshouldbeabletoopen.
 Ifthestoragedeviceofthereextinguishingsystemcanberechargedandrestoredtoworkwithin72
hours, the reserve capacity may not be set. Otherwise, the reserve capacity shall be set at 100% of the
original storage capacity of the system.
 Thedesigntemperatureofthereextinguishingsystemshouldbe20°C.
 During the project's construction, the appropriate location should be selected according to the actual sit-
uation on the site to install the pipeline. The position and size marked in the drawings are for reference
only.
 Theprotectionareashouldhaveexhaustequipment.Afterthereextinguisherisreleased,theexhaust
gas should be exhausted before the person can enter for maintenance
 Electric louvers can be selected for the air inlet device, and electric louvers + fan + control modules can
be selected for the exhaust device. Start logic of louvers and fans: when the concentration of combus-
tible gas in the container rises above the set value, the combustible gas detector acts and outputs the
fan and louvers start command signals through relay signals and start all fans and louvers at the same
time to discharge the combustible gas in the container; When the concentration of combustible gas in
the container is reduced below the set value, the combustible gas detector outputs the fan and louver
stop command signal through the relay, and all fans and louvers are stopped at the same time. When
the UPS power is exhausted, the louvers should be open. The louvers should have a manual closing
button.
3. Installation and Acceptance
 The system shall be constructed and accepted in strict accordance with EN 15004-1-2019 and the de-
signandconstructiondrawingsapprovedbytherecontroldepartment.
 Install according to design drawings, equipment installation instructions, and on-site conditions;
 Thebottlegroupofthereextinguishablesystemshouldensurethedesignsize,rmxation,conven-
ient operation and observation, and beautiful appearance.
