SWDM40 OPERATION & MAINTENANCE MANUAL
●Corresponding action schematic
Push the right pilot handle rightward
Push the right pilot handle leftward
4.11 CROWD WINCH WIREROPE TENSION
★Note: This model doesn’t support this function.
● “Button 1- Working switch” in the membrane key panel is not connected (The light above
the key is off)
● “Button 5- Pressurized winch wirerope tension switch” in the membrane key panel is
connected(The light above the key is on)
