SWDM40 OPERATION & MAINTENANCE MANUAL
226
11.2 MAIN PARAMETERS
Items
Parameter
Max. pile diameter
mm
1000
Max. pile depth
Friction Kelly
m
22
Dimension
Working
mm
4978X2320X8805
Transportation
mm
6245X2320X3379
Operating weight
（
working
）
t
17
Engine
Model
4TNV98CT
Rated power
kw/rpm
53.7@2100
Rotary drive
Max. torque
kN.m
45
Rotation speed
r/min
5~50
Crowd system
Max. pressure
kN
60
Max. line pull
kN
70
Max. stroke
mm
1500
Main winch
Max. line pull
kN
60
Max. line speed
m/min
30
Rope diameter
mm
18
Auxiliary winch
Max. line pull
kN
15
Max. line speed
m/min
30
Rope diameter
mm
10
Mast Inclination
Lateral


3
Forward

5
Backward

90
Chassis
Crawler width
mm
450
Chassis length
mm
3224
**
As the improvements of the product, technical parameters are subject to change without
notice in advance.
