SWDM40 OPERATION & MAINTENANCE MANUAL
such as forward inclination (rear inclination), leftward inclination, rightward inclination to
protect mast structure damage from continuous inclination; Erecting mast installation steps are
as below:
Press and hold the button SB1 on left handle to cancel mast limit of forward and rearward
inclination, the lateral limit for mast is still valid in the process.
● To cancel the function of mast four-direction limit, set the space length as “9999” on the
“debugging interface”.
4.6 MAIN WINCH
●Push the left pilot handle forward/backward
●
Corresponding action schematic
Push the left pilot handle forward
Push the left pilot handle backward
