8.2.2 Oil
Oil use for SWDM40 can be found in the table 8-2-2.
Table 8-2-2 Oil capacity and type
No.
Components or
system
Capacity
（L）
Oil type
Remark
1
Fuel tank
245
0# diesel（4°above）
-10# diesel
（
-5°-4°
）
The diesel for lower environment temperature can be
selected for real condition.
2
Engine oil capacity
14
CJ-4 and above CK-4
15W-40
1.Viscosity: 15W-40
2.Choose oil of suitable viscosity according to
environment temperature
3. The filling capacity depends on the scale of engine
oil dipstick(between LOW and HIGH)
3
Engine coolant
4.5
Antifreeze ： 50% Ethylene
glycol or Propylene glycol
+50% purified water
1. Don’t mix antifreeze of different types.
2. The filling capacity of antifreeze is up to the upper
sight glass of radiator or the filler.
4
Radiator water tank
14
5
Hydraulic oil tank
154
Forth, Total or International
standard 68
＃
antiwear
hydraulic oil
Cylinder (luffing, mast, crowd, track extension &
retraction etc.), fill up to the upper scale line of tank
level gauge; Fill up to the lower scale line when the
cylinder extend and retract fully).
6
Swing reduction gearbox
5.5
Industrial gear oil 220
In the reduction gearbox
7
Travel reduction gearbox
2×7.5
Industrial gear oil 220
8
Rotary drive housing
35-40
Industrial gear oil 220
9
Rotary drive reduction
gearbox
2×7
Industrial gear oil 220
10
Main winch reduction
gearbox
6
Industrial gear oil 220
11
Auxiliary winch
reduction gearbox
3
Industrial gear oil 220
12
Swing gear ring
30kg
Lithium base grease
13
Left & right crawler
tension cylinder
As required
Lithium base grease
Adjust track tension to specified requirements.
Note：
 The oil capacity in above table is only for reference, please see the standard at the oil
filler. When cylinder is fully retracted or extended, hydraulic oil should be at upper
scale or lower scale on the level gauge.
