In each interface of the "Monitoring Port", follow operations can be done.
Click "Page 1" (key 1) to enter the "Port Monitoring Page 1" (Figure 3.2.1-9).
Click "Page 2" (key 2) to enter the "Port Monitoring Page 2" (Figure 3.2.1-10).
Click "Page 3" (key 3) to enter the "Port Monitoring Page 3" (Figure 3.2.1-11).
Click "Page 4" (key 4) to enter the "Port Monitoring Page 4" (Figure 3.2.1-12).
Click "IO Module" (key 5) to enter the "IO Module Monitoring" page (Figure 3.2.1-13).
Click "Membrane" button (key 6) to enter “Membrane Key Monitoring" page (Figure 3.2.1-14).
Click "Return" (key 8) to enter the "Main Monitoring" interface (Figure 3.2.1-7).
The "Port Interface" monitors the working value of all the ports, such as equipment controller,
IO module, membrane button, and also provides the instructions.
There are two kinds of numerical value under detecting:
①
The number value is 0/1, 0 shows that input voltage or output voltage of the port is zero, 1
shows that the input or output voltage of the port is 24V. When the value is "0", the instruction
about the port is DI_ or DO_.
②
The analog value displays in numeral form, that means the input or output voltage of the
port or the electricity current. There's AI_ or AO_ displays in the port instruction.
In the column of the port, the marked letter, such as “4:AI_P1”, which indicate that the fourth
stitch of the controller (or IO module), the numerical tube is marked with “P1”, which is the
analog value.
3.2.1.9 GPS Status Display Interface
Enter “GPS Status Display Interface” by clicking “GPS” in the “Main Monitor Interface”
(Figure 3.2.1-7).
