Suzuki Ozark - SPECIFICATIONS

5-6 FUEL SYSTEM
SPECIFICATIONS
E-03: USA E-17: Sweden E-24: Australia E-28: Canada E-33: California (USA)
I.D. NO. LOCATION
Carburetor has an I.D. number 1 printed on its body.
ITEM
SPECIFICATION
E-03, 24, 28 E-17 E-33
Carburetor type MIKUNI BS29 ←←
Bore size 29 mm ←←
I.D. No. 05G0 05G2 05G1
Idle r/min 1 500 ± 100 r/min ←←
Float height 17.1± 1.0 mm
(0.67 ± 0.04 in)
←←
Main jet (M.J.)
#137.5 ←
#
Jet needle (J.N.) 4DJ24-1st ←←
Needle jet (N.J.)
P-OM ←
Throttle valve (Th.V.) #100 ←←
Pilot jet (P.J.)
#17.5 ←
#
Pilot screw (P.S.)
2 turns out ← PRE-SET
Throttle cable play
(pulling cable)
3 – 5 mm
(0.12 – 0.20 in)
←←
Starter (enricher) plunger cable play 0.5 – 1.0 mm
(0.02 – 0.04 in)
←←
