9-24 SERVICING INFORMATION
DRIVE TRAIN
CHASSIS
ITEM N·m kgf-m lb-ft
Front propeller shaft flange coupling bolt 45 4.5 32.5
Rear drive shaft housing nut 23 2.3 16.5
Rear propeller shaft flange coupling bolt 30 3.0 21.5
Rear drive gear case bolt 23 2.3 16.5
Rear drive gear oil filler plug 33 3.3 24.0
Rear drive gear oil drain plug 33 3.3 24.0
ITEM N·m kgf-m lb-ft
Handlebar clamp bolt 23 2.3 16.5
Steering shaft holder bolt 23 2.3 16.5
Steering shaft nut 49 4.9 35.5
Steering knuckle nut (Upper & Lower) 45 4.5 32.5
Tie rod end nut 35 3.5 25.5
Tie rod locknut 29 2.9 21.0
Front shock absorber mounting nut (Upper) 57 5.7 41.0
bolt (Lower) 55 5.5 40.0
Wishbone arm pivot nut 65 6.5 47.0
Wheel hub nut (Front) 75 7.5 54.0
nut (Rear) 100 10.0 72.5
Wheel set nut (Front & Rear) 50 5.0 36.0
Brake master cylinder mounting bolt 10 1.0 7.0
Brake hose union bolt 23 2.3 16.5
Front brake air bleeder valve 7.5 0.75 5.5
Front brake disc bolt 23 2.3 16.5
Front brake caliper mounting bolt 26 2.6 19.0
Front brake pad mounting bolt 18 1.8 13.0
Front brake caliper holder pin 18 1.8 13.0
Front brake caliper holder slide pin 23 2.3 16.5
Footrest bolt
8 mm 26 2.6 19.0
10 mm 55 5.5 40.0
Rear brake pedal nut 12 1.2 8.5
Rear brake cam lever nut 11 1.1 8.0
Rear brake panel 60 6.0 43.5
Rear shock absorber mounting bolt (Upper) 55 5.5 40.0
nut (Lower) 60 6.0 43.5
Rear swingarm pivot nut 85 8.5 61.5
Headlight mounting bolt 5 0.5 3.5
Headlight beam adjusting screw 3 0.3 2.0
