Suzuki Ozark - REMOVAL AND DISASSEMBLY

7-46 CHASSIS
REMOVAL AND DISASSEMBLY
• Remove the rear wheel. (7-10)
• Remove the rear hub. (7-11)
• Disconnect the brake cables.
• Remove the drum cover bolts.
• Remove the drum cover 1 by using the slotted screwdriver.
• Remove the brake drum 2.
• Remove the brake shoes 3 and springs 4.
NOTE:
If reinstalling the removed brake shoes, mark the brake shoes
with direction (leading and trailing) of installation before remov-
ing the brake shoes.
