8-6 ELECTRICAL SYSTEM
CHARGING SYSTEM
TROUBLESHOOTING
Generator
Regulator/rectifier
Ignition switch
Fuse
Battery
Load
No accessories
No current leaks
Incorrect
Continued on next page
• Remove accessories
• Short circuit of wire harness
• Faulty electrical equipment
• Faulty battery
• Abnormal driving condition
Battery runs down quickly.
Check accessories which use excessive
amounts of electricity.
Check the battery for current leaks.
(8-8)
Measure the charging voltage between
the battery terminals. (8-8)
Correct
Current leaks
Accessories
are installed
To Next Page
