Suzuki Ozark - FRONT SUSPENSION

7-28 CHASSIS
FRONT SUSPENSION
CONSTRUCTION
1 Front shock absorber
2 Upper wishbone arm
3 Bushing
4 Lower wishbone arm
5 Steering knuckle
6 Snap ring
7 Knuckle end
A Shock absorber mounting upper nut
B Shock absorber mounting lower bolt
C Wishbone arm pivot nut
D Steering knuckle nut
E Tie rod end nut
ITEM N·m kgf
.
m lb-ft
A 57 5.7 41.0
B 55 5.5 40.0
 C 65 6.5 47.0
 D 45 4.5 32.5
 E 35 3.5 25.5
"
