3-8 ENGINE
ENGINE INSTALLATION
Remount the engine in the reverse order of engine removal.
Pay attention to the following points:
NOTE:
* The engine mounting nuts are self-locking.
* Once the nut has been removed, it is no longer of any use. Be
sure to use new nuts, and then tighten them to the specified
torque.
• Engage the secondary driven gear shaft to the universal joint.
ITEM N·m kgf-m lb-ft
A 23 2.3 16.5
B 55 5.5 40.0
C 55 5.5 40.0
D 55 5.5 40.0
"
