9-16 SERVICING INFORMATION
FUEL HOSE ROUTING
Carburetor
Clip
Clip
Fuel hose
Fuel valve
Install the curve of the fuel hose to the fuel valve.
Fuel tank
Fuel valve vacuum hose
