8-18 ELECTRICAL SYSTEM
Measure the ignition coil primary peak
voltage. (8-19)
NOTE: The ignition coil peak voltage
inspection method is applicable only with the
multi circuit tester and the peak volt adaptor.
Inspect the ignition coil. (8-20)
Measure the pickup coil peak voltage and
resistance. (8-20 to 8-21)
NOTE: The pickup coil peak voltage
inspection is applicable only with the multi
circuit tester and the peak volt adaptor.
Inspect the spark plug.
(2-6)
• Faulty spark plug
• Improper spark plug
connection
• Faulty pickup coil
• Faulty ignition coil
• Faulty CDI unit
• Open circuit in wiring
harness
• Improper ignition coupler
connection
Correct
Correct
Incorrect
Incorrect
Incorrect
Correct
Incorrect
Correct
To Next Page
