SERVICING INFORMATION 9-13
Emergency switch
Emergency switch
(E-17)
Front brake switch
Ignition switch
Ignition switch lead wire
Clamp
Forward
Steering
upper bracket
Horn button
(E-17, 24)
Handlebar switch (L)
Clamp
Clamp
Clamp
Clamp
Brake lever switch
Parking brake switch
Horn button (E-17, 24)
Starter cable
0 – 20˚
Generator
lead wire
Starter motor
lead wire
Ground
wire
Neutral
switch
lead wire
A
Starter motor
Starter
motor
B
Starter
motor
lead wire
Neutral
switch
lead wire
VIEW A
VIEW B
