HOW TO USE THIS MANUAL
TO LOCATE WHAT YOU ARE LOOKING FOR:
1. The text of this manual is divided into sections.
2. The section titles are listed in the GROUP INDEX.
3. Holding the manual as shown at the right will allow you to find
the first page of the section easily.
4. The contents are listed on the first page of each section to
help you find the item and page you need.
COMPONENT PARTS AND WORK TO BE DONE
Under the name of each system or unit there is an exploded view which provides work instructions and other
service information (e.g.; tightening torque, lubricating points, and locking agent points).
Example: Rear suspension
ITEM N·m kgf
-
m lb-ft
A 55 5.5 40.0
B 60 6.0 41.0
C 85 8.5 61.5
"
1 Rear shock absorber
2 Swingarm
3 Bushing
A Rear shock absorber mounting upper bolt
B Rear shock absorber mounting lower nut
C Swingarm pivot nut
To Next Page
