3-52 ENGINE
REASSEMBLY
Reassemble the recoil starter in the reverse order of disassem-
bly. Pay attention to the following points:
• When installing the spiral spring, hook the spiral spring end 1
with the recoil starter case.

• Apply SUZUKI SUPER GREASE “A” to the spiral spring.
 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
• Turn the starter rope on the reel properly.
• After installing the spiral spring, engage the part 2 of the reel
with the spiral spring end 3.
• Hook the rope onto the hook part 4 of the reel, turn the reel
clockwise three of four times with the rope.
• Install the ratchet related parts.
NOTE:
Apply SUZUKI SUPER GREASE “A” to the shaft and ratchet.
 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
Wear hand and eye protection when installing the reel,
since the spring may quickly unwind and cause an
injury.
