GEARSHIFTING 9-5
• Align the pin groove A with the pin B when installing the
stopper plate 1.
• Tighten the gear shift cam bolt 2.
Gearshift cam bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
• Install the springs, pins and pawls to the shifter. Wider side A
of pawl should be positioned outside.
• With the pawls held in pushed position, install the pawl lifter
3.
