9. FINAL DRIVING MECHANISM
9-9
Gear box side
Use inner bearing puller to remove the final shaft
needle bearing, gear shift shaft bearing and
counter shaft bearing from the cover inner side.
Special tool:
Inner bearing puller
Remove cir clip of final shat out side bearing.
Remove final shat out side bearing.
Special tool:
Inner bearing puller
Remove oil seal from gear box cover and discard
the seal.
Install new bearings into gear box cover inner
side.
Special tool:
Needle bearing driver (4905)
Bearing driver (6302)
Bearing driver (6204)
Install new final shaft oil seal into gear box cover,
and then install new out side bearing.
Special tool:
Oil seal driver (30x40x5)
Bearing driver (6205LU)
Inner bearing puller
To this chapter contents
Cir clip
Inner bearing puller
Bearing driver
