4. FUEL SYSTEM
4-1
Mechanism Diagram ............................ 4-1
Precautions in Operation..................... 4-2
Trouble Diagnosis................................ 4-3
Carburetor Remove / Install ................ 4-4
Air Cut-Off Valve .................................. 4-5
Throttle Valve.......................................4-6
Float Chamber......................................4-7
Adjustment of Idle Speed....................4-9
Fuel Tank..............................................4-10
Air Cleaner............................................4-11
Mechanism Diagram
4
Home page
Contents
Carburetor
Fuel unit
Inlet pipe
Auto fuel cock
Fuel tank cap
Fuel strainer
Insulator
Fuel tank
