Sym Track Runner 200 - Steering and Suspension Service

15. STEERING / SUSPENSION
15-1
Mechanism Diagram ··························15-1
Operational Precautions····················15-2
Trouble Diagnosis······························15-2
Steering Handle··································15-3
Steering Shaft·····································15-6
Steering Tie-Rod ································ 15-7
Knuckle··············································· 15-8
Front Cushion ···································· 15-9
Suspension Arm ································ 15-10
Toe-In·················································· 15-11
Mechanism Diagram
4. 6kgf-m
2.4kgf-m
5.0kgf-m
3.4kgf-m
4.0kgf-m
15
Home page
Contents
5.0kgf-m
5.0kgf-m
5.0kgf-m
3.6kgf-m
5.0kgf-m
