9. FINAL DRIVING MECHANISM
9-1
Mechanism Diagram - transmission cover
······························································ 9-1
Mechanism Diagram - transmission·· 9-2
Precautions in operation ···················· 9-3
Trouble Diagnosis······························· 9-3
Disassembly of Final Driving Mechanism
······························································ 9-4
Inspection of Mission Mechanism···· 9-6
Bearing Replacement ························ 9-8
Re-assembly of Final Driving
Mechanism ········································· 9-10
Mechanism Diagram - transmission cover
Home page
Contents
9
Safety switch
Gasket
Gear oil fill bolt
1.1~1.5kgf-m
Oil level gauge
Transmission plate
Oil seal
(14x28x7)
Boss
Return spring
Eng. Hanger rubber bush
Boss
Eng. Hanger rubber bush
To Next Page
