Sym Track Runner 200 - Drive Face Service

8. V-BELT DRIVING SYSTEM/KICK STARTER
8-7
Drive Face
Removal
Remove left crankcase cover.
Hold drive face with universal holder, and then
remove drive face nut.
Remove drive face.
Remove driving belt and movable drive face comp
from crankshaft.
Remove ramp plate.
Remove weight rollers from movable drive face.
Crankshaft
Drive face boss
Movable drive face
Ramp plate
Movable drive face
Weight roller
To this chapter contents
Universal holder
