Sym Track Runner 200 - Alternator and Starting Clutch Service

10. ALTERNATOR/STARTING CLUTCH
10-1
Mechanism Diagram ··························10-1
Precautions in Operation···················10-2
Right Crankcase Cover Removal······10-3
A.C.G. Set Removal····························10-3
Flywheel Removal ······························10-3
Starting Clutch ··································· 10-4
Flywheel Installation·························· 10-7
A.C.G. Set Installation························ 10-7
Right Crankcase Cover Installation·· 10-7
Mechanism Diagram
5.0~6.0kgf-m
1.0~1.4kgf-m
0.8~1.2kgf-m
10
