Sym Track Runner 200 - Electrical System Service

17. ELECTRICAL SYSTEM
17-1
Mechanism Diagram ··························17-1
Maintenance Data·······························17-2
Technical Specification······················17-2
Trouble Diagnosis······························17-3
Battery·················································17-4
Charging System································17-5
Ignition System···································17-8
Starting System··································17-10
Meters················································· 17-12
Light / Bulb········································· 17-13
Switch / Horn······································ 17-16
Fuel Unit············································· 17-19
Cooling Fan Thermo Switch ············· 17-20
Thermo unit········································ 17-21
Water Temperature Indicator Light·· 17-21
Mechanism Diagram
Starter relay
Winker relay
Spark plug
AC. Generator
Fuse box
Battery
Ignition coil
Fuel unit
Main switch
C.D.I. Unit
Regulator rectifier
Shift gear
control unit
Horn
Start & light
& winker &
horn switch
Headlight relay
Home page
Contents
Thermo unit
Hazard
control unit
17
