13. BODY COVER
13-9
Footrest
Remove
Loosen the 6 screws, which connect the front
fender and footrest, these 6 screws just be twin
the front fender two side.
Loosen the 6 screws, which connect the rear
fender and footrest, these 6 screws just be twin
the rear fender two side.
Loosen the 4 bolts, and then remove footrest bar
and footrest.
These 4 bolts just are the right and left footrest.
Installation
Install in reverse order of removal procedures.
To this chapter contents
6 screw
3 screws
2 bolts
