16. REAR BRAKE & REAR WHEEL & REAR CUSHION
16-17
Rear Cushion
Removal
Support the frame.
Remove cotter pin, and remove rear cushion
under bolt.
Remove cotter pin, and remove rear cushion
upper bolt.
Installation
Install rear cushion upper bolt, and install cotter
pin.
Install rear cushion under bolt, and install cotter
pin.
Rear cushion under bolt
Cotter pin
To this chapter contents
Rear cushion upper bolt
Cotter pin
