13. BODY COVER
13-8
Remove front fender upper side 1 bolt.
Loosen the front fender two side bolts.
Loosen the 6 screws, which connect the front
fender and footrest, these 6 screws just be twin
the front fender two side.
Remove power outlet, right and left winker
couplers.
Remove front fender.
Installation
Install in reverse order of removal procedures.
1 bolt
6 screw
To this chapter contents
2 bolts
Winker coupler
Power outlet couplers
